Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine

    Buy cheap Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine from wholesalers

    Buy cheap Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine from wholesalers
    • Buy cheap Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine from wholesalers
    • Buy cheap Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine from wholesalers
    • Buy cheap Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine from wholesalers

    Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine

    Ask Lasest Price
    Brand Name : Perfect Laser
    Model Number : PE-UV-0609
    Certification : CE /ISO /TUV /SGS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 400 sets per month
    Delivery Time : 3-7working days
    • Product Details
    • Company Profile

    Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine

    Small Business 900x600mm CMYK+WV Industrial Automatic Digital UV Flatbed Printing Machine

    (Model:PE-UV-0609)

    ※Product Introdution


    The flat printer uses high speed, high precision, high quality double nozzles. UV flatbed printing with a width of 600*900 mm and high production efficiency makes it possible to save more time and reduce costs. To meet the diverse needs of various industries, different materials and color inkjet customers, a flat printer is able to achieve an excellent production efficiency with rich colorful colors.



    ※Product Features


    1.The flat printer imported well-known brand linear guide rails, long service life, high stability of movement, greatly reduce the noise generated by the equipment during high-speed motion, control within 40 decibels.

    2.UV flatbed printing To prevent accidents caused by human error, improve nozzle protection, it is easy to handle any debugging material using a unique system for avoiding collision of the nozzles.

    3. Ink cartridge installation automatic alarm system: When the ink level is less than one-third, the ink cartridge automatically lights up, allowing continuous printing, production smooth.

    4.The flat printer is equipped with professional RIP software: to ensure bright color output, the use of well known brand colour management software.

    5.To improve the speed and efficiency of UV lamp alternate curing, uv flatbed printing with a bidirectional print is being used. To improve the speed and accuracy of printing, the scale shall be affixed to a work table.

    6. The scale is printed on the worktable to increase the speed and accuracy of printing.



    ※ Application


    1.In order to meet the needs of customers' specific requirements, we are using a flat printer for home and shop decor.

    2. Oil painting wall, decorative painting and other industries:the uv flatbed printing can replace the traditional hand-painted, improve production efficiency.

    3. Advertising signage display board display industry: Flat printer can print on the surface of advertising boards of various materials to reduce production costs.

    4. Leather textile printing industry: The uv flatbed printing can print on leather and fabric with high precision and high efficiency.


    ※Technical Parameters


    Model typeFlat Printer PE-UV0609
    Print head technologyDrop on-demand piece head
    NO. of Print heads6
    Print head typeRicoh
    Printing resolution360*360dpi,360*720dpi,360*1080dpi,720*720dpi, 720*1440dpi,720*3600dpi,720*21600dpi
    Printing modeUni-direction and Bi-directional
    Printing speed(2 print heads)4 PASS6 PASS8 PASS
    8M²/hr6M²/hr4M²/hr
    Media handlingVacuuming media fixation platform
    File formatTIFF,JPEG,Postscript 3,EPS,PDF,etc
    Color controlConform to ICC standard,with function of curve and density adjustment
    InterfaceUSB
    Curing lampOsram LED lamp
    RIP softwareUSA PP PHOTOPRINT
    Ink typeUV curable ink
    Print colorCyan,Magenta,Yellow,Black,White
    Printing size600mm*900mm
    Printable productsArts & Crafts:barrette,USB flash memory,glasses frame,watch belt,cigarette case,lighter,badge,stationery products,toys,cellphone case,etc.
    Media thickness100mm(200mm optional)
    Print head and feeding driveAC high precision servo motor
    Power consumption50Hz/60Hz,220V(±10%),>20A
    Operation conditionTemperature 20℃~28℃,Reative humidity 40%`60%
    Dimensions(LxWxH)1600mm*1680mm*1000mm
    Net Weight200KG
    X shaft beltJapan Fuji film industrial wire belt
    X axis /Y axis servo motorTaiwan Delta
    X axis beamTwo times tempered high strength steel, high hardness, no deformation
    X/Y axis print towline and wire harnessGermany IGUS
    Y shaft drive screwImported grinding rod
    Ink car lift rail brandTaiwan HIWIN mute linear guide rail

    Packaging & Delivery


    1. Prompt deliver at the very day.
    2. Sophisticated and professional logistic agent.
    3. Well-trained and disciplined packing team.

    4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.

    Competitive Advantages


    1. We offer high quality products at competitive price in quick delivery.
    2. 100% custom pass guaranteed.
    3. Good after-sale service.
    4. Flexible and Untraceable payment terms.
    5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
